Hawkeye System - Model: HS2010 - Specifications

Performance: Blade Tip Sensor
Measurement Range
Zero point location
Measurement speed
Blade Thickness
Blade Angle
Resolution
Repeatability
Operational:
Power
Purge Gas
Temp Range
Laser Output
(HS2010ER-S-T1VHPMP)
buttp_b.gif buttp_n.gif buttp_n.gif butlf_n.gif butlf_b.gif butlf_b.gif butlf_b.gif
Copyright Hawk Aerospace, LLC
|
|
|
(860) 659-8241
+/- 0.070"/1.78mm
.250"/6.35mm
>12000 RPM with 120 blades (Higher speeds available)
.007"/.178mm
+/- 35 Deg relative to sensor face
.00002"/.5um
.0001"/2.5um
24VDC Nominal
Moisture-free, oil-free, clean air at 3 to 5 psi
15 - 55 degrees C
<5mW @ 635nm - 670nm Class IIIa
